Description
Technical specification:Performance
Tipping load (ISO 14397-1) 1958 kg
Rated operating capacity (ISO 14397-1) 979 kg
Pump capacity 64.70 L/min
Pump capacity (with high flow option) 101.10 L/min
Push Force 2377 daN
System relief at quick couplers 23.8-24.5 MPa
Max. travel speed (high range – option) 17.3 km/h
Max. travel speed (low range) 11.8 km/h
Engine
Make / Model Bobcat 2.4L, 97/68 EC Stage V
Fuel Diesel
Cooling Liquid
Power at 2600 RPM: 50.7 kW
Torque at 1800 RPM (SAE J1995 Gross): 252.0 Nm
Number of cylinders 4
Displacement 2392 cm3
Fuel tank 93.70 L
