Description
Automatic Seam Welding Machine – MAC/20640 with PLC and digital LCD display
Technical Specifications:
- Max. Capacity: 90 cpm *
- Body Diameter: 99-165mm
- Body Height: 110-350 mm *
- Sheet Thickness: 0.18-0.3 mm
- Copper Wire Diameter: 1.38-1.5 mm
- Seam Overlap : 0.6 mm
- Welding Speed : 14-21 m/min. *
- Welding Frequency : 400 Hz (static)
- Total Connecting Load : 18 kVA
- Working Air Pressure: 6 Bars Min.
- Water pressure: 4 bars
- Cooling water consumption : 8 lt/min
- Temperature of water supply : 12-16 ◦ C
