Description
Technical Specifications:
Machine length; 7,200 mm
Machine width; 1,500 mm
Machine height; 2,000 mm
Machine mass; 3,600 kg
Full width; 1,500 mm
Working length of the machine; 6,100 mm
Working depth of the machine; 1,150
Max bending angle of sheet metal; 145⁰
Number of carrying terms; 6
Number of bending cylinders; 6
Reinforcement of bending bar; YES
Movement of the upper jaw; Hydraulic
Movement of the bending bar; Hydraulic
Moving shears for cutting; Hydraulic
Engine power; 4.0 kW
Frequency regulation of the motor; YES
Additional motor for sheet metal movement; 0.55 kW
Rudder; Schneider Electric
Software; CNC – SA
Pressure when closing the sheet metal; 100 bar
