Description
Technical Specifications:
Machine length; 8,200 mm
Machine width; 1,500 mm
Machine height; 2,000 mm
Machine weight; 4,400 kg
Overall width; 1,500 mm
Machine working length; 9,100 mm
Machine working depth; 1,150
Maximum sheet bending angle; 145⁰
Number of support arms; 8
Number of bending cylinders; 8
Bending bar reinforcement; YES
Upper jaw movement; Hydraulic
Bending bar movement; Hydraulic
Cutting shear movement; Hydraulic
Motor power; 5.5 kW
Motor frequency control; YES
Motor speed for sheet feed; 0.55 kW
Controller; Schneider Electric
Software; CNC – SA
Pressure when closing the sheet metal; 100 bar
