Description
Technical Sheet:
- Bending capacity: 170–175 ton CNC press brake with 3200 mm working length
- Geometry: 2600 mm between columns, 400 mm throat depth, 480 mm open height
- Stroke & speeds: 200 mm stroke; up to 180 mm/s approach and 160 mm/s return speed
- CNC control: Delem DA‑53T, typically 4+1 axes with programmable backgauge
- Drive system: Electro‑hydraulic synchronized system for high precision bending
- Power consumption: approx. 22 kW installed power
