Description
Technical Specifications:
| Category |
Specification |
| Type |
Spotmix II base station |
| Dimensions |
| • Length |
0.9 m |
| • Width |
0.85 m |
| • Height |
1.63 m |
| • Weight |
approx. 218 kg |
| Vessel Capacity |
| • Mixing vessel |
approx. 60 l |
| • Transfer vessel |
approx. 60 l |
| • Max. useful capacity (density: 0.65 kg/l) |
approx. 27 kg |
| Feedstuff Requirements |
| • Pourable |
(moisture depends on feedstuff) |
| • Grain size |
only floury feed; pellets up to 4 mm diameter, length max. 15 mm |
| • Feed must be |
free from foreign bodies |
| Mixing Vessel |
| • Vessel type |
Welded stainless steel on one weighing cell |
| • Operation |
Flap with pneumatic or electric rotary drive and position detection |
| • Motor |
0.55 kW, 58 rpm gear motor |
| Transfer Vessel |
| • Vessel type |
Welded stainless steel on two weighing cells |
| • Gear motor |
0.55 kW, 58 rpm |
| • Chamber lock |
0.18 kW, 14 rpm gear motor |
| • Operating speed |
18 rpm at Spotmix Speed |
| Limits of Use |
| • Min. ambient temperature |
frost-free |
| • Max. ambient temperature |
+40°C |
