Description
Technical Specifications:
| model | FQJ-1100A | FQJ-1300A | FQJ-1600A |
| diameter of unwinding | 1400mm | 1400mm | 1400mm |
| width of slitting | 1000mm | 1200mm | 1500mm |
| diameter of rewinding | 1000mm | 1000mm | 1000mm |
| width of rewinding | 30mm | 30mm | 30mm |
| slitting speed | 10-150m/min | 10-150m/min | 10-150m/min |
| slitting accuracy | ±0.3mm | ±0.3mm | ±0.3mm |
| power | 10kw | 11kw | 12kw |
| electric | 380V/50Hz Tri-phase | 380V/50Hz Tri-phase | 380V/50Hz Tri-phase |
| requirement of air pressure source | 5.5kg/cm2×0.5m3/min | 5.5kg/cm2×0.5m3/min | 5.5kg/cm2×0.5m3/min |
| weigh | 2800kg | 3000kg | 3300kg |
| overall dimension | 3800×2500×1800mm | 3800×2800×1800mm | 3800×3100×1800mm |
1 using circular knife cutting, cutting high precision, convenient operation, the cutter can be adjusted;
2 the A and B axis independent winding, convenient handling;
3, shaft adopts automatic tension control, inflatable shaft, orderly and compact rewinding of finished products;
4 feeding frame adopts pneumatic automatic lifting function;
5.Automatic discharging device for waste
6 this machine adopts frequency conversion. Microcomputer automatic control, selection of imported photoelectric deviation device, automatic meter, alarm stop, tension digital display and other advanced features.
