Description
Technical Specifications:
Comprising of:
SJSZ—65/30 single screw extruder:
Screw diameter : 65mm
The length and diameter ratio of screw : 30:1
Material of screw: 38CrMoALA ,Under nitrogen treatment
The depth of nitrogen layer of screw: 0.4-0.6mm,hardness: HV>74
Driving motor power 30 kW
Capacity: 60/80 kg/h
Heating Drying hopper:
Available volume: 80L,Capacity: 50kg,Heating power: 4.5kw,blower powder: 0.12kw
Moulds
Forming machinery:
Lubricating system ：auto oil lubricating system (controlled by motor )
Reduction gearbox ：umbrella hard tooth surface reducer one set
Hauling off speed ：15-25 m/min
Cooling mode ：circulate water for cooling
Driving power ：4KW motor with speed frequency regulation
Counting mode ：shaft programmable code technology
Adjustment of forming machine ：machinery adjustment ，motor power ：0.4KW
