Description
Technical specifications:
Number Of Columns: pcs 4
Diameter Of Vertical Discs: Mm 1000-1800
Diameter Of Horizontal Discs Mm 450(*)
Main Motor Power Kw 110
Motor Power Of Horizontal Discs Kw 18,5
Motor Power Of Bridge Movement (Left/Right) Kw 2.2
Up/Down Motor Power Of Bridge Movement Kw 3
Motor Power Of Cabin Movement Kw 5,5
Hydraulic Motor Power Of Horizontal Discs Kw 1.1
Motor Power Of Wagon Kw 2.2
Total Electrical Power Kw 150
Wagon Speed mt/min 10
Robot Bridge Movement Motor Power kw 1.5
Lifting Lowering Robot Motor Power kw 7.5
Vacuum Motor Power of Robot kw 2.2
Block Dimension Mm 3500-220(***)-2400
Overall Dimension Mm 9900-8200-6500
Machine Weight Kg 18000
