Description
Technical Specifications:
1 Model LT-12050TKA-12KW
2 MAXIMUMPIPELENGTH ≤12300mm
3 TOTALPOWER /
4 TAILINGS 0
5 YTRAVEL (FRONTMACHINEBED) 12750mm
6 YTRAVEL (BACKMACHINEBED) 12300mm
7 XTRAVEL 1050mm
8 ZTRAVEL 760mm
9 X.YPOSITIONACCURACY ±0.05mm/1000mm
10 X.YREPEATPOSITIONACCURACY ±0.03/1000mm
11 ANSWERPART 12MSTANDARD
12 MAXIMUMPIPEDIAMETER
Round:70-540mm
Square:70-500mm
Hbeams:70-540mm, cross line≤710mm
Uchannel:70-540mm, cross line≤710mm
Anglesteel:70-540mm, cross line≤710mm
14 LASERPOWER 12000W
15 POWERSUPPLY 380v50Hz±10%
16 MAXIMUMPIPELENGTHFORANSWERPART ≤12100mm
17 MAXIMUMGSPEED 0.5G
18 MAXIMUMHOLDINGWEIGHTOFSINGLEPIPE 3000kg
19 SINGLESUPPORTLOAD-BEARING ≤300kg
20 MAXIMUMFEEDRATE 50m/min
21 MAXIMUMROTATIONSPEED 25r/min
22 AUXILIARYGAS O2.N2.Air
23 Voltage 380V3phase50HZ
24 Workingenvironment Temperature5-45℃,humidity<70%
