Jiangsu Faygo Union Machinery Co. Ltd. – CW and UW profile production line – SJSZ51/105

Description

Technical Sheet:

TOTAL POWER: 32.85 kW

Components & Specs

1. Material Loader (ZJ300)

• Charging capacity: 300 kg/h
• Pipe length: 4 m
• Material case volume: 150 kg
• Motor power: 1.5 kW
• Contact parts: Stainless steel

---

2. Conical Twin Screw Extruder (SJSZ51/105)

• Screw diameter: Φ51/105 mm
• Speed: 1–35 rpm
• Main motor: 18.5 kW (WEG)
• Heating power: 16 kW
• Cooling: 0.23 kW × 3 sets
• Vacuum pump: 2.2 kW
• Heating zones: 9 total
• Capacity: 60–100 kg/h

---

3. Vacuum Calibration Table

• Length: 3 m
• Vacuum pump: 4 kW
• Water pump: 2.2 kW
• Air drying motor: 0.75 kW
• Adjustment motor: 0.75 kW
• Dimensions: 4000 × 1100 × 1200 mm

---

4. Haul-off Machine

• Motor power: 1.1 kW × 2 pcs
• Speed: 0.3–6 m/min
• Dimensions: 2600 × 1000 × 1700 mm

---

5. Cutting Machine

• Max profile size: 300 × 100 mm
• Saw diameter: Φ350 mm
• Cut motor: 2.2 kW
• Sawdust suction fan: 0.75 kW

---

6. Stacker

• Length: 4 m
• Material: Stainless steel board
• Dimensions: 4000 × 900 × 950 mm

---

7. Co-Extruder (SJ30/25)

• Screw diameter: 30 mm
• L/D ratio: 25:1
• Main motor: 2.2 kW

---

Power Summary

• Material Loader: 1.5 kW
• Extruder: 18.5 + 16 + (0.23 × 3) + 2.2 = 37.39 kW
• Calibration Table: 4 + 2.2 + 0.75 + 0.75 = 7.7 kW
• Haul-off: 1.1 × 2 = 2.2 kW
• Cutting: 2.2 + 0.75 = 2.95 kW
• Co-Extruder: 2.2 kW
