Technical Sheet:
Power requirements: 196-253 V, 10 A, 50/60 Hz, 1 phase, NEMA L6-20P
Air supply requirements: 7-12 bar (100-175 psi)
Approximate air consumption: 113 L/min (4 CFM)
Internet connection: Hardwired or wireless add-on, minimum 10+ Mbps upload and download
Roller force: Variable up to 567 kg (1,250 lbs)
Rim width range: 38 mm to 521 mm (1.5 in to 20.5 in)
Rim diameter range: 254 mm to 762 mm (10 in to 30 in)*
Maximum tyre diameter: 1,016 mm (40 in)
Maximum tyre width: 356 mm to 1,016 mm (14 in to 40 in)*
Maximum tyre weight: 79 kg (175 lbs)
Radial and lateral runout accuracy: 0.051 mm (0.002 in)
Imbalance resolution: ± 0.28 g (0.01 oz)
Placement accuracy: 512 positions, ± 0.35°
Balancing speed: 300 rpm
Motor: Programmable drive system with DC motor
Usable power cord length: ~3,505 mm (138 in)
