Description
Technical Sheet:
Clamping force: 1,200 kN (≈ 120 tonnes)
Drive technology: Energy-efficient servo-hydraulic drive system
Screw diameter: 40 mm
Injection volume (theoretical): 213 cm³
Injection weight (PS): 194 g
Injection rate: 131 g/s
Injection pressure: 189 MPa
Plasticizing rate: 23.1 g/s
Maximum screw speed: 300 rpm
Pump motor power: 18.5 kW
Heater power: 11.75-12.85 kW
Installed power consumption: approximately 30-31 kW (pump motor + heaters)
Mould opening stroke: 360 mm
Minimum mould height: 150 mm
Maximum mould height: 450 mm
Maximum daylight: 810 mm
Distance between tie bars (H×V): 410 × 410 mm
Platen dimensions (H×V): 615 × 615 mm
Ejector stroke: 120 mm
Ejector force: 33 kN
Machine dimensions (L×W×H): 4.95 × 1.24 × 1.94 m
Machine weight: 4.0 t
Hopper capacity: 25 kg
Oil tank capacity: 140 l
Control system: KEBA controller with touchscreen interface
Automation features: Euromap 67 robot interface, core-puller functions, air-blow interfaces, closed-loop temperature control, and compatibility with automated production cells
