Technical Sheet:
- Production capacity: 150–250 kg/h of soft biscuits with a working width of 700 mm and tray size of 700 × 900 mm.
-
- Dough preparation system: 150 kg/batch horizontal dough mixer with inverter-controlled speed, hydraulic tilting, and stainless-steel construction.
-
- Automated dough handling: Dough transport trucks, hydraulic dough truck tilter, and automatic cutting/conveying system for continuous feeding to the forming section.
-
- Rotary moulding unit: Tray-type rotary moulder with interchangeable moulds for producing various biscuit shapes and sizes, including customized designs.
-
- Advanced process control: Siemens PLC and touchscreen HMI, frequency-controlled drives, and dual-motor transmission for precise and reliable operation.
-
- Food-grade hygienic design: Product-contact parts made of SUS304 stainless steel, food-grade PU belts and rollers, and integrated waste dough collection system for easy cleaning.
-
- Electrical and mechanical specifications: 380 V / 50 Hz power supply, 4.5 kW installed power, machine dimensions of 3,500 × 900 × 1,200 mm, and approximate weight of 1,300 kg.
