Description
General Specifications:
- Capacity: 120-200 T/H
- Total Motor Power: 53 KW
- Feeding Size: Fractions of the final product may be declared in advance by the buyer.
- Fractions to be Received: 3 different sizes can be received.
- Electrical Parts: Siemens or Schneider.
Vibrating Feeding Bunker:
- Model: KBB-7
- Bunker Volume: 7 m³
- Side Body Supplements: 5mm ST-37
- Body Sheet: 15mm ST-37
- Feeding Options: Excavator, loader, and truck.
- Features: Walking, control, maintenance platform, and protection enclosures suitable for occupational safety.
Vibrating Washing Screen:
- Model: TE-1645
- Motor Power: 15 KW (Gamak – Emtaş or equivalent brand)
- Speed: 1000 RPM
- Screen Decks: 3 decks
- Dimensions: Length: 4500 mm, Width: 1600 mm
- Screen Surface: 7.2 m²
- Screen Angle: 18°
- Bearings: Nachi, SKF, FAG, or equivalent brand.
- Springs: 8 pieces, special production from steel.
- Wear Plate: 10mm ST52 at material pouring area.
- Features: Wear-resistant screen meshes, durable steel springs, and protection enclosures suitable for occupational safety.
Spiral Washer:
- Model: HY 600 Double Spiral Washer
- Spiral Dimensions: Ø 600×6000 mm
- Washer Dimensions: 1400 x 6550 x 1900 mm
- Motor Power: 2×5.5 KW
- Body Material: ST-37 A1 quality metal sheet
- Water Consumption: 65-230 m³
- Features: Belt pulley system, helix shafts, and high durable motor.
Conveyor Belts:
- Screen Feeding Conveyor Belt: Length: 7000 mm, Width: 800 mm, Motor Power: 5.5 KW
- Front Stock Conveyor Belt: Length: 5400 mm, Width: 700 mm, Motor Power: 4 KW (folding type during shipment)
- Side Stock Conveyor Belts: Length: 6800 mm, Width: 500 mm, Motor Power: 5.5 KW (folding type during shipment)
- Features: Wear-resistant, directional rollers to prevent belt slippage, vulcanized rubber drum.
Mobile Chassis:
- Chassis Feet: 200x200x8mm special profile telescopic feet (180x180x8mm).
- Axles: 2 axles with air brakes and signalization equipment.
- Hydraulic System: Optional hydraulic legs, bunker covers, stock and feedback conveyor belts, and crusher.
- Features: Emergency safety buttons, hydraulic locks for safety, and easy transportation and installation.
