Description
General Machine Specifications:
- Number of interpolated axes: 5
- Carriage stroke (X axis): 4100 mm
- Max speed (X axis): 0–30 m/min
- Bridge stroke (Y axis): 2200 mm
- Max speed (Y axis): 0–30 m/min
- Vertical stroke of the head (Z axis): 240 mm
- Max speed (Z axis): 0–15 m/min
- Head rotation (C axis): Infinite rotation
- Waterjet head tilting movement (A axis): +/- 60°
- Maximum cutting depth: 250 mm
- Maximum slab dimensions: 4000 x 2100 mm
- Work table load capacity: 3000 kg
- Slab detector stroke: 25 mm
- Water consumption (3 bar): 5 l/min
- Air consumption: 100 Nl/min at 7 bar
- HP water intensifier electrical power: 37 kW
- HP water intensifier max working pressure: 4137 bar
- HP water intensifier max flow: 3.8 l/min
- Abrasive tank capacity: 200 l
- Standard electric voltage: 400V ±10% / 50Hz
- Total installed power (without optional): 44 kW
