Description
Technical sheet:Highlights
- Turning Diameter: Up to 320 mm
- Guideway Size: 35 for high stability and durability
- Bar Capacity: Ø 65 mm
- Turret: 12-positional VDI 30
- Optional Y Axis: ± 50 mm
- Control Panel: 21.5” Multi-Touch with CELOS for Siemens 840D or Fanuc i-Series
Main Specifications
- Main Spindle: Integrated synchronous spindle motor, 5500 rpm, 14 kW
- Counter Spindle: Integrated spindle motor, 6000 rpm, 9 kW
- X Travel: 250 mm (V3/V4), 185 mm (V6)
- Y Travel: ±50 mm (V4/V6)
- Z Travel: 550 mm (V3/V4), 520 mm (V6)
- Tool Turret: 12 stations, VDI 30, driven tools
Control System
- CELOS® with Siemens 840D sl Operate
- DXF-Reader: For importing DXF files
- Digital Manufacturing Package: IoTconnector, Machine Data Connector, NETservice
