Description
Technical Specifications:
Maximum power 152 hp
Operating weight 17.7 t
Bucket capacity 0.66 m³
| Emission standard | Stage V |
| Engine | Develon DL06V |
| Engine power | 113 kW / 152 hp at 2000 rpm |
| Overall width (standard / wide axle) | 2530 mm / 2780 mm |
| Wheel base | 2650 mm |
| Tread width | 1944 mm |
| Travel speed (creep / low / high) | 3 / 10 / 37 km/h |
| Maximum traction force | 10800 kg |
| Minimum turning radius | 5872 mm |
| Maximum swing speed | 10.6 rpm |
| Maximum swing torque | 5825 kgf·m |
| Max. digging reach (Mono / Arti boom) | 8525 mm / 9140 mm |
| Max. digging depth (Mono / Arti boom) | 4920 mm / 5745 mm |
| Max. digging height (Mono / Arti boom) | 8975 mm / 10210 mm |
| Main pumps max flow | 2 × 167 l/min |
