Description
Technical Sheet:
-
Cooling capacity: 86.6 kW (74,481 kcal/h) at 30°C ambient / 15°C outlet water
-
Conditions: Inlet 30°C water, outlet ~15°C; requires glycol antifreeze
-
Ambient range: 5–38°C; water temp min -6.8°C
Compressor & Refrigerant
-
Refrigerant: R410A
-
Compressors: 2 hermetic scroll (Danfoss)
-
Circuits: 1
Evaporator & Pump
-
Evaporator type: Plate heat exchanger (Euroclass B insulation)
-
Water pump: Centrifugal (MAS-DAF), 4 kW power, 14.9 m³/h flow, 2.9 bar pressure
-
Tank: 190 L (30% ethylene glycol)
-
Pipe diameter: Inlet/outlet 1″ 1/2 (DN40)
Fans & Air
-
Fan type: Axial, 2 fans (2 x 0.6 kW)
-
Air flow: 21,600 m³/h
-
Noise level: 52–83 dBA (at 10m)
Electrical & Dimensions
-
Input power (pump off): 19.3 kW; nominal current 37 A
-
Power supply: 400V 50Hz 3N (IP54 protection)
-
Controls: Microprocessor (Carel), Eaton Moeller components
-
Dimensions (L x W x H): 2020 x 1050 x 1880 mm
-
Weight: 618 kg
