Description
Technical Specifications:
| rotection class | IP20 IP54 |
|
| power supply | 240V/50Hz 120V/60Hz |
|
| Memory | 2 GB compact flash card | |
| Height/transverse adjustment labeler | manual | |
| Belt dimensions (L x W) | 300 x 300 mm (6 kg, 12kg) – 3/6 kg 400 x 300 mm (6 kg, 12 kg) – 3/6 kg 700 x 300 mm (6 kg) – 3/6 kg |
|
| Ambient air humidity | 20-90% non-condensing | |
| Product Dimensions Range (L x W x H) | 80 – 700 x 40 – 300 x >1 – 250 mm | |
| Labeling performance | max 50 ppm | |
| Resolution | 8 dot/mm (optionally 12 dot/mm) | |
| Barcode variations | EAN/UPC 8 EAN/UPC 13 EAN/UPC 128 Code 2/5 int. Code 39 Code 128 GS1-128 PDF417 |
|
| Label roll | Core diameter 76 mm (optionally 40 mm) Outer diameter 300 mm |
|
| Product dimensions (L x W x H) | max. 300 mmx 400 mm x250 mm max. 300 mm x700 mm x 250 mm |
|
| Voltage variants | 120 V 240 V |
60 Hz 50 Hz |
| Label size | min. B 30 mm x H 30 mm, max. B 100 mm x H 100 mm (depending on applicator type, further dimensions available as special version) | |
| Interfaces | Ethernet (TCP/IP) RS232 RS422 TTY |
|
| Temperature range | -10 °C -10 °C to +40 °C |
Storage Operation |
| Dimensions (L x W x H)/(D x W x H) | H: 15 cm H: 20 cm H: 17 cm |
|
| Thermal transfer ribbon | Core diameter 25,4 mm Outer diameter 81 mm |
|
| Printing speed | max 250 mm/s | |
| Print width | 80 mm (optionally 104) | |
| Applicator | Blasapplikator Stempelapplikator Bandapplikator |
|
| Printing technology | Thermal direct (optionally thermal transfer) | |
| Display properties | 12″ LCD display with touchscreen function | |
| Weighing range | 3/6 kg 12 kg 6 kg 6 kg |
e=1/2 g e=2 g e=1 g e=2 g |
