Description
Technical Data
Description MIN MAX UM
Panel height* 10 60 mm
Height of edge-banding material 14 64 mm
Thickness of edge-banding material in rolls 0,4 3 mm
Thickness of edge-banding in strips** 0,4 12 mm
Panel protrusion from track 25 mm
Panel length*** 140 3200 mm
Min panel width (with length 140 mm) **** 85 mm
Min panel width (with length 250 mm) **** 50 mm
Feed chain speed 12 m/min
Panels gap** 450 650 mm
Dust extraction system for each operating unit 1 hood Ø 100 mm
Pneumatic connection 7 bar
Working voltage 400 V/50 Hz threephase + neutral
Control voltage 24 V – CC
Static frequency inverter 200 Hz
Glue pot capacity** 2 (approx.) Kg
Glue pot heating time at ½ load 10 (approx.) minutes
Total power 9.4 kW
