BetonMec Srl – Batching plant – Loading and batching plant for 8 aggregate types

Description

Technical Specifications:

Aggregate Storage & Dosing System

Number of bins: 3–4 compartments
Bin type: Steel modular hoppers
Discharge system: Pneumatic or hydraulic gates
Feeding system:
Weigh hopper capacity: ~1500–3000 kg

Cement Storage & Feeding System

Silos: Vertical steel silos, Capacity: ~50–100 tons each, Quantity: 1–3 units
Cement transfer: Screw conveyors (Ø200–300 mm typical)
Mixer type: Twin-shaft compulsory mixer
Batch capacity: ~1.0–3.0 m³ per cycle
Hourly output: ~30–120 m³/h
Mixing time: 30–60 sec per batch

Automation & Control System

Control platform: PLC-based system
Data management: Production logging & traceability

Electrical System

Main panel: MCC (Motor Control Center)
Installed power: ~50–150 kW (estimated)
Voltage: Low voltage (400V / 50Hz typical)
