Description
Technical Specifications:
A MACHINE LENGTH 5950 mm (234.3 in)
A1 MACHINE LENGTH (BLADE) 6610 mm (260 in)
B WHEELBASE 3040 mm (119.7 in)
C MACHINE HEIGHT 2970 mm (116.9 in)
D MACHINE HEIGHT (REMOVED ROPS) 2200 mm (86.6 in)
E DRUM WIDTH 2130 mm (83.9 in)
F MACHINE WIDTH 2260 mm (89 in)
F1 MACHINE WIDTH (BLADE) 2440 mm (96 in)
G CURB CLEARANCE 400 mm (15.7 in)
H GROUND CLEARANCE 430 mm (16.9 in)
I DRUM DIAMETER 1500 mm (59.1 in) /*1685 mm (66.3 in)
J DRUM THICKNESS 35 mm (1.4 in) /*25 mm (1.0 in)
MANUFACTURER Deutz TCD4.1 L4
POWER ACCORDING TO ISO 14396 115 kW (154 HP)
EXHAUST GAS AFTER-TREATMENT EGR+DOC+DPF+SCR
EU Stage V / U.S. EPA Tier 4 Final
FREQUENCY I 25–29 Hz
(1500–1740 vpm)
25–29 Hz
(1500–1740 vpm)
FREQUENCY II 25–35 Hz
(1500–2100 vpm)
25–35 Hz
(1500–2100 vpm)
AMPLITUDE I 2.06 mm (0.081 in) 1.93 mm (0.076 in)
AMPLITUDE II 0.96 mm (0.038 in) 0.88 mm (0.035 in)
CENTRIFUGAL FORCE I 242–325 kN
(54,403–73,063 lbf)
242–325 kN
(54,403–73,063 lbf)
CENTRIFUGAL FORCE II 110–215 kN
(24,728–48,334 lbf)
110–215 kN
(24,728–48,334 lbf
