Technical Sheet:
Structure & Flight Performance
-
Max takeoff weight: 175 kg (spraying/spreading) / 165–170 kg (lifting) at sea level
-
Max diagonal wheelbase: 2330 mm; unfolded dimensions: 3220×3224×975 mm
-
Max wind resistance: <6 m/s; configurable flight radius: 2 km
-
Hovering accuracy (RTK): ±10 cm horizontal/vertical
Propulsion
-
Motors: stator 155×16 mm, 60 KV
-
Propellers: 62-inch carbon fiber composite (8 pairs)
Spraying System
-
Spray tank: 100 L HDPE, payload 100 kg; max flow 40 L/min (4 nozzles optional)
-
Effective spray width: 5–13 m; droplet size 50–500 μm
Spreading System
-
Spread tank: 150 L, internal load 100 kg; max rate 400 kg/min (fertilizer)
-
Effective spread width: 3–10 m; granules 0.5–10 mm
Lifting System
-
Lift capacity: 100 kg (single battery) / 80 kg (dual); cable length 10–15 m
Sensors & Safety (Safety System 3.0)
-
mmWave radar + quad vision: detection ≤60 m, avoidance up to 13.8 m/s
-
FOV: horizontal 360°, vertical up to 272° (laser radar); min avoidance height ≥1.5 m
