Description
with truck body on chassis SCANIA 4×2 – curtainsider type Z-180 Basic
Technical specifications
Chassis adaptation, Basic
Wheel configuration, 4×2
(Read only code) Wheel configuration certified, 4×2
Chassis height, Low
Suspension system, air front + air rear
Steering wheel position, left hand
Dimensions:
- Chassis width, 2550 mm
- Max truck height, 4 meters 96/53/EG
- Axle distance, 5750 mm
- Dimension JA/BEP L020 (Bodywork Exchange Parameters), 3400 mm
- Rear frame overhang (price), 160 cm
- (Read only code) Steering angle 1st, RH turn, 50 max
- (Read only code) Steering angle 1st, LH turn, 50 max
Weights
- Legal weight 1st axle, 7100 kg
- Legal weight 2nd axle, 13000 kg
- GVW legal, 26000 kg
- GVW legal part 2, 0 kg
- (Read only code) GVW technical, 20500 kg
- Gross Train Weight, GTW Legal, 40000 kg
- GTW technical, 40000 kg
- GTW technical part 2, 0 kg
- GTW technical part 3, 0 kg
- ADR maximum train weight, >/= 44000 kg
Engine
- Propulsion , combustion engine
- Fuel, diesel
- Fuel type, Diesel
- Engine stroke volume, 9 litres
- Emission level, Euro 6
- Engine type, DC09 141 360 hp Euro 6 /Japan Emission 2016
