Technical Sheet:Description
Laser source: fiber laser technology
Wavelength: yellow 577 nm
Power at tissue up to: 2000 mW
Pulse duration: 10 ms to continuous
Single spot modes: single, repeat, painting, continuous
SubLiminal® mode: train of microsecond pulses
adjustable duty cycle: 5% to 100%
Resume® function: available in MultiSpot and
SubLiminal® modes
Pattern:
MultiSpot mode: single spot, squares, circles, triple arc,
macular grid
SubLiminal® mode: single spot, squares, customizable
macular grid
Spot size:
Single spot: continuously variable from 50 µm to 400 µm
Pattern: continuously variable from 100 µm to 400 µm
Integrated slit lamps:
Haag Streit type: Quantel Medical (CSO 9900 5x)
Zeiss type: Quantel Medical (CSO 9800 5x)
Aiming beam: 635 – 650 nm
Size: 174.2 (H) x 97 (W) x 72 (D) cm
68.58’’ (H) x 38.19’’ (W) x 28.35’’ (D)
Weight: 60 kg – 132 lbs
Cooling: by Peltier effect
Power requirements: 100 to 240 VAC, 250 VA, 50/60 Hz
