Description
Technical Specifications:
nominal cooling capacity kcal/h 24940 kw 29
input power kw 11.22
power supply 3PH~380V/50HZ
refrigerant type R410A
type of control thermostatic expansion valve compressor
type hermetic scroll
power(kw) 8.8
condenser type finned copper tube + low noise outer rotor fan
cooling air flow(m3/h) 10000
evaporator
type Water tank coil type
chilled fluid flow(m3/h) 5.00
volume(L) 200
inlet and outlet pipe
diameter(inch) 2
pump power(kw) 1.5
lift(m) 20
safety protection
compressor over temperature, over current, high and low pressure, phase
sequence, phase-missing
weight kg 45
