Description
Technical Specifications:
Scheimpflug camera: Camera digital CCD camera
Light source blue LED (475 nm UV-free)
Processor DSP with 400m operations/s
Speed 100 images in 2 seconds
Measurement range
Axial length 14 – 40 mm
Curvature 3 – 38mm, 9 – 99D
Precision ± 0.1D
Reproducibility ± 0.1D
Operating distance 80mm (3.1 in)
Dimensions (W x D x H) 275 x 320 – 400 x 500 – 530 mm
(10.8 x 12.6 – 15.7 x 19.7 – 20.9 in)
Weight 8.4 kg (18.52 lbs)
Voltage 24 V DC
Frequency 47 – 63 Hz
Max. power consumption 42 W
Recommended computer specifications CPU Intel Core i5-6600,
