Description
Technical Sheet:
- Engine: KUBOTA 4-cylinder V6108-TIEF5, Stage V
- Maximum power: 143 hp
- Displacement: 6,124 cm³
- Fuel / AdBlue capacity: 230 L / 20 L
- Transmission: Power Shift, 24 forward / 24 reverse speeds; Auto mode; 3 ranges × 8 speeds
- Drive: Four-wheel drive with electrohydraulic front-wheel-drive engagement (On / Off / Auto)
- Rear PTO speeds: 540 / 540E / 1000 / 1000E rpm
- Hydraulic system: Closed-centre CCLS/LS system; 115 L/min pump flow
- Rear lift capacity: 7,000 kg at the lift-arm ends
- Hydraulic outlets: Four pairs, with mechanical flow-control valves
- Tyres: 600/65 R38 and 480/65 R24
- Cab: Air-conditioned comfort cab with air-suspended seat, tinted curved glass, roof window and armrest-integrated control console
- Turning system: Bi-Speed Turn; maximum steering angle stated as 55%
- Weight: 6,000 kg without ballast weights, in standard configuration
- Dimensions: 4,620 mm length; 2,690 mm wheelbase; 2,890 mm height
Eligible for automation if with Autopilot steering control and ISOBUS monitor
