Description
Technical Data
- Volumetric Flow: 4.05 m³/min at 8.0 bar
- Power Consumption: 28.5 kW at 8.0 bar
- Maximum Pressure: 8.00 bar
- Motor Efficiency: 92.7% at full load
- Motor Efficiency Class: IE3
- Motor Power: 22.0 kW
- Motor Speed: 2960 rpm
- Motor Protection Class: IP 55
- Voltage Tolerance: ±10%
- Power Supply: 400V / 3 / 50Hz
- Sound Pressure Level: 69 dB(A)
- Oil Filling Quantity: 10.2 liters
Dimensions and Weight
- Dimensions (W x D x H): 800 mm x 1460 mm x 1530 mm
- Weight: 620 kg
Cooling and Environmental Data
- Cooling Air Flow: 5000 m³/h
- Pressure Dew Point: 3°C at 20°C ambient temperature and 30% relative humidity
- Refrigerant / Quantity: R-513A / 0.41 kg
- Global Warming Potential (GWP): 629
- CO2 Equivalent: 0.26 tons
- Compressed Air Connection: G 1 1/4
- Ambient Temperature Range: 3°C to 45°C
