Description
Technical Sheet:
| Feature |
PM7 |
PM5 |
PM3 |
DRY |
| Spindle Type |
Jaeger |
Jaeger |
Jaeger |
SFK |
| Power |
970 W (0.97 kW) |
390 W (0.39 kW) |
390 W (0.39 kW) |
500 W (0.50 kW) |
| Max RPM |
60,000 |
60,000 |
60,000 |
60,000 |
| Dimensions (W×D×H) |
979×695×818 mm |
870×695×818 mm |
450×545×630 mm |
450×545×630 mm |
| Weight |
220 kg |
215 kg |
195 kg |
91 kg |
| Tool Changer |
20 tools |
13 tools |
13 tools |
16 tools |
| Material Changer |
8 discs |
8 discs |
– |
– |
| Axis Technology |
5-axis |
5-axis |
5-axis |
5-axis |
| Motors |
Servomotors |
Servomotors |
Servomotors |
Stepper motors |
| Ionizer |
Yes |
– |
– |
– |
| Zero-point Clamping System |
Yes |
Yes |
Yes |
– |
| Internal CNC PC |
Yes |
Yes |
Yes |
– |
| Operation Modes |
Wet & Dry |
Wet & Dry |
Wet & Dry |
Dry only |
with PrograPrint CAM software
