Description
Technical Sheet:Power Supply & Consumption
- Voltage:
- 110–120 V, 50–60 Hz
- 200–240 V, 50–60 Hz
- Admissible Voltage Fluctuations: ±10%
- Max Power Consumption:
- 12 A at 110–120 V
- 8.5 A at 200–240 V
- Vacuum Pump:
- Max Power Consumption: 250 W
- Final Vacuum: < 50 mbar
Dimensions
- Furnace (Closed):
- Depth: 495 mm
- Width: 320 mm / 395 mm (with cooling tray)
- Height: 320 mm
- Firing Chamber:
- Diameter: 90 mm
- Height: 80 mm
Temperature & Weight
- Max Firing Temperature: 1200 °C
- Weight:
- P710 G2: 18.7 kg
- P510 G2: 18.7 kg
- P310 G2: 15.6 kg
