Description
Technical Specifications:
• output power 22 kW (3-phase), output current 0–32A, voltage 400 VAC ±15%
• Type 2 connection, 1× connector, cable 5m
• input voltage 400 VAC ±15% (3P + N + PE)
• input frequency 45–65 Hz
• OCPP 1.6J (upgradable to 2.0.1)
• 4G (optional), Ethernet, WiFi, Bluetooth
• RFID Mifare ISO 14443, Plug & Charge, App start
• OTA firmware updates
• over voltage, over current, overload, over temperature, under voltage, short-circuit, emergency stop,
surge and grounding protection
• IP65, IK10, plastic housing, dimensions 277.5 × 135 × 408 mm, leakage protection AC 30mA + DC 6mA
(Type A)
• operating temperature -40°C to +55°C, humidity 5–95% RH (non-condensing), maximum altitude
height 2000m
• certificates: CE, CB, TR25 (IEC 61851-1, IEC 61851-21-2, TR25-1
