Description
Techncial Specifications:
Max. Loading Size6100 mm x 3300 mm
Min. Loading Size 2,440 mm x 1,830 mm
Sucker Rotating Arm Double-side / Bilateral
Glass Thickness 3 – 19 mm
Transport Speed 0 – 35 m/min (Adjustable)
Loading Cycle ≤ 60 s
Suction Depth ≤ 700 mm
Vacuum Pressure-70 ~ -99 kPa
Power-Off Vacuum Hold Time ≤ 15 min
Stations (Glass Racks) 6
Arms (Each Side) 6
Suckers (Each Arm) 4
Power 14.5 kW
