Description
Technical Specifications:
Nominal Voltage (V) 51.2
Nominal Capacity (AH) 314
Usable Capacity (KWH) 16.076
Charge Voltage (V) 58.4
Discharge Voltage (V) 40
Battery System Discharge Current (Standard) 157
Battery System Discharge Current (Max) 200
Peak Charge/Discharge
Current(A) 240(2S)
Communicaiton RS485/RS232/CAN
Working Temperature 0℃~50℃ Charge -10℃ ~50℃ Discharge
Shelf Temperature -20℃~60℃
certification CE/IEC/UL/UN38.3/MSDS
Design Life 10 years+
Size(mm) 450*944*276
Weight(KGS) 120
[1]
Cycle Life >8000
Enclosure Protect Level IP32
